120 Psi Passenger Cars Tpms Solar Tire Pressure Monitor
2.21 inch Universal external solar Tire pressure monitoring system for passenger cars 433.92mhz
Specifications
1. Display can ba charged by solat or mini USB charging slot.
2. DIY installation, no need connect cable/cigarette lighter.
3. High-definition colorful LCD display shows pressure&temperature of all tire in circular scrolling motion.
4. Alert immediately when temperature or pressure of tire under abnormal condition. Large capacity battery display.
5. Innovative technology, super long standby time, super long working life, visual and sudible warning, aleeping mode available.
6. Pressure range: 0~14bar
Receive host parameters
| PCB thickness |
1.0mm |
| PCB copper thickness |
1OZ |
| Whole board weight |
75g |
| Working temperature |
-30-80℃ |
| Power interface |
micro usb |
| Working voltage |
3.3V-4.2V |
| Bright screen standby current |
5.8mA |
| Highlight mode current |
12mA |
| Sleep current |
0.1mA |
| Receive sensitivity (open loop test) |
-90dbm |
parameter
Sensor size: 2.1cm (width)*1.7cm (height)
Sensor plastic part material: nylon/glass fiber
Shell temperature resistance: -50℃-150℃
Valve thread specifications: 8V1 external thread
Valve thread material: phosphor copper
Battery replacement tool size: 4.2cm (width) * 0.6cm (height)
Battery replacement tool material: ABS
Anti-theft nut material: brass nickel plated
Anti-theft nut weight (single): 0.7g
Waterproof rubber ring specifications: diameter 1.6cm, wire diameter 1.0mm
Waterproof rubber ring material: rubber
Sensor weight: 9.6g±1g
Features
Sensor low battery warning
When the battery power of any sensor transmitter is lower than 2.4V, the buzzer sounds an alarm, and the corresponding tire icon and low battery icon flash continuously.Each time you restart the device, it will only give an alarm for the first time, and it will be automatically eliminated after 30 seconds of alarm.
Our Services & Strength
1. OEM Manufacturing welcome: Product, Package, make new color box with your brand, your logo on the remote or main unit.
2. We will reply you for your inquiry in 24 hours.
3. Normal we will ship the product within three days after receiving your deposit for small order.
4. After sending, we will track the products for you once every two days, until you get the products. When you got the
goods, test them, and give us a feedback.
5.We will choose the most suitable way to delivery for you, if you have special requirement. Please let us know.
FAQ
1. who are we?
We are based in Shenzhen China, start from 2013,sell to Domestic Market(00.00%),Southeast Asia(00.00%), Oceania(00.00%),Western
Europe(00.00%),South Asia(00.00%),North America(00.00%),Eastern Europe(00.00%),Africa(00.00%),Mid East(00.00%),Eastern
Asia(00.00%),Central America(00.00%),Northern Europe(00.00%),Southern Europe(00.00%),South America(00.00%). There are total about
11-50 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Car Alarm,Car Reversing Aid, button start, remote start, keyless erntry,Car tpms & Truck tpms
4. why should you buy from us not from other suppliers?
Welcome to our website. Shenzhen EGQ Cloud technology co., ltd has more than 10 years of OEM & ODM experience for car
accessories. Our qualified R & D team can meet all customization needs.We can make new color box and print your logo with your
brand TKS
5. what services can we provide?
Accepted Delivery Terms: EXW；
Accepted Payment Currency:USD;
Accepted Payment Type: T/T,PayPal,Western Union;
Language Spoken:English, Chinese
