Bluetooth Ten Sensors 2.4Ghz Tire Pressure Monitoring System

Bluetooth Ten Sensors 2.4Ghz Tire Pressure Monitoring System

  • Bluetooth Ten Sensors 2.4Ghz Tire Pressure Monitoring System
Bluetooth Ten Sensors 2.4Ghz Tire Pressure Monitoring System
Product Details:
Place of Origin: China
Brand Name: EGQ
Certification: CE,FCC,ROHS,IATF16949:2016
Model Number: BLE TPMS
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiation
Packaging Details: boxs
Delivery Time: 7-15 work days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 10000 sets per month
Contact Now
Detailed Product Description
Max Pressure: 120 Psi Product Name: BLE Ten Tire Pressure Monitoring System ( Bluetooth TPMS)
Frequency: 2.4Ghz Function: Pressure Unit Setting
Self-checking Current: 2.5mA Sleep Current: 2.4uA
Highlight:

Bluetooth Tire pressure monitoring system

,

2.4Ghz Tire pressure monitoring system

,

2.4Ghz tire pressure monitor

Bluetooth Ten Sensors 2.4Ghz Tire Pressure Monitoring System



Universal internal Bluetooth ten sensors Tire pressure monitoring system for Passenger car 2.4Ghz



Hot sale bluetooth external tpms tire pressure monitoring system

Once BLE tire sensor installed in wheel, tire pressure and temperature can be displayed in cellphone with APP. During travel, tire pressure and temperature displayed in real time and send alert when statistics' abnormal. For your safety, please read manual before using, thank you!



Function



Parameter Setting



Tire quantity selection setting



Pressure unit setting



Features



1. Prevent accidents



2. Real-time monitoring of tire pressure and temperture to prevent puncture



3. Extend tire life



4. Reduces wear on the suspension system



5. Make driving more economical





sensor parameters



Sensor dimensions 7.1cm*5.3cm
Sensor plastic part material Nylon / glass fiber
Temperature resistance of the shell -50℃-150℃
Volume resistivity of silica gel ≥1.0×1013Ω•cm
The silicone heat-resistant -50℃-200℃
Antenna material Phosphor copper nickel platin
Metal material of valve Aluminium (oxidation treatment)
Rubber pad material EPDM
Valve weight 14.0g
Full weight of sensor (including valve nozzles) 26.5g±2g
Sensor working temperature - 40℃-85℃
Battery model CR2032
Battery capacity 350mAh
working voltage 2.1V-3.3V
Emission current 140uA
Self-checking current 2.5mA
Sleep current 2.4uA
Battery temperature resistant -40℃-125℃
Emission frequency 2.4GHZ
Emissive power 0dbm







WARNING

Support cellphone with Bluetooth 4.0 or above Do NOT support Cellphone with Bluetooth lower than 4.0. Product displays by cellphone. During driving, please be careful when viewing tire pressure and temperature in cellphone If tire pressure accelerates down or up continuously, please stop car and check if theres any problem with the tire. This product can read tire pressure and temperature, but it cannot avoid sudden accident motorcycle by tire It's important to use tire with high quality slightly tire leakage makes tire pressure decreases over time is normal. It has nothing to do with this product installation.



FAQ



Q: Are you trading company or manufacturer ?

A: We are factory.



Q: How long is your delivery time?

A: For TPMS Product,we will send goods to you within 15 work days after we receive your 70% Balance due.

For OEM products,the delivery time is 30-35 work days after we receive your 70% Balance due.



Q: What is your terms of payment ?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.OR T/T, L/C, D/A and western union.
